Greetwin 8 band 2.4G 5.8g Gpsl1 Gpsl2 900MHz 433MHz anti uav system drone jammer

Item No.: GW-UAV-BP15M
Greetwin 8 band 2.4G 5.8g Gpsl1 Gpsl2 900MHz 433MHz anti uav system drone jammer
Description
Description

Product Description

Greetwin 8 band 2.4G 5.8g Gpsl1 Gpsl2 900MHz 433MHz anti uav system drone jammer

 Greetwin High Power 6 Bands Uav Mult Frequency Anti Drone JammerGreetwin High Power 6 Bands Uav Mult Frequency Anti Drone Jammer

Product Parameters
All Parameters:
External Antennas: 8pcs Omnidirectional High Gain (6-8 dBi) antennas, one per frequency band.
VSWR - disconnect/ short antenna protection
Internal Li-lon battery - Continues amplifying 1.5h / Standby 48 h/ Charging time 5h
Operational Power: 90-260 V AC using a directional AC power 12/24 VDC
Weight: No more than 22 Kg (main backpack unit - with battery, without external antennas)
Jammer system
Frequency Bands Output Power
1. 2400-2485MHz 50 W
2. 1560-1620MHZ 50 W
3. 5725-5850MHz 30 W
4. 860-930MHz 40 W
5. 5725-5850MHz 30 W
6. 5150-5250MHz 30 W
7. 433MHz 10 W
8. 1170-1280MHz 10 W
Electrical
PROTECTION VSWR protection
Overheat Protection:
70° cut off operation
65°resume of operation
OPERATIONAL POWER [90-260] VAC / 24V DC Internal Power Supply
COOLING Forced Air Cooling
CONTROLS & INDICATORS On/Off switch & indicator +
control to select bands (each band 1 button)
BATTERIES Internal Li Ion 20AH
Mechanical
MODE OF DEPLOYMENT Rapid Deployment/Mobile
CASING Rigidized backpack
Environmental
OPERATING TEMPERATURE RANGE -20˚c to +65˚c
RESISTANCE IP52
RELATIVE HUMIDITY 5%-95% non condensing


-----Application-----
Sensitive Areas, Prisons,Oil Refineries,Bases, Protected Areas, Drone Jamming


Application

Law enforcement personnel such as bomb squad , critical mission protection, S.W.A.T, security forces, bomb teams, counter-terrorism units, anti-drug units, border control units, and checkpoint personnel will greatly benefit from the deployment of any portable RF interference solution. They can be more effective in reducing opportunities for offenders to leak information in the enforcement process.
