Product Feature
* Wide band and high gain.
* Elegant appearance, simple installation, stable performance.
* Good performance in anti-vibration and resistant to aging.
* Suitable for indoor Wall mounted or Hold pole installation.
| ELECTRICAL | |
| Frequency Range | 824-960/1710-2500-MHz |
| Bandwidth | 136/790-MHz |
| Gain | 7-dBi |
| Beamwidth | H:65-° E:55-° |
| VSWR | ≤1.5 |
| Polarization | Vertical |
| Max power | 100 -W |
| Nominal Impedance | 50 -Ω |
| MECHANICAL | |
| Connector | N female or customized |
| Antenna Dimension | 208*178*45-mm |
| Weight | 0.6-kg |
| Rated Wind Velocity | 60-m/s |
| Mounting Kits | L bracket & U bolt |
